System
|
CPU: VVTK-1000 SoC
Flash: 8MB
RAM: 64MB
Embedded OS: Linux 2.4 |
| Camera Control |
PTZ camera control through RS-485
Supported devices and protocols: DynaDome/SmartDome, Pelco D, LiLin
Supports CGI command serial driver |
| Video |
Compression: MJPEG & MPEG-4
Streaming:
Simultaneous dual streams
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 multicast streaming
MJPEG streaming over HTTP or HTTPS
Supports 3GPP mobile surveillance
Frame rates:
MPEG-4: Up to 30/25 fps at 352x240 (NTSC) / 352x288 (PAL)
MJPEG: Up to 30/25 fps at 352x240 (NTSC) / 352x288 (PAL) |
| Audio |
Compression
GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps
Line level input: up to : Up to1
Supports two-way audio
Supports audio mute |
| Networking |
10/100 Mbps Ethernet, RJ-45
Protocols: IPv4, TCP/IP, HTTP, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS and PPPoE |
| Alarm and Event Management |
Triple-window video motion detection
1 D/I & 1 D/O for external sensor and alarm
Event notification using HTTP, SMTP, or FTP |
| Security |
Multi-level user access with password protection
IP address filtering |
| Users |
10 clients on-line monitoring at the same time |
| Abmessungen |
Tiefe: 130mm
Breite: 78.35mm
Höhe: 33.85mm |
| Weight |
Net: 198 g |
| LED Indicator |
System activity and network link indicator |
| Power |
12V DC
Power consumption: Max. 4 W |
| Approvals |
CE FCC |
| Operating Environments |
Temperature: 0 ~ 50 °C (32 ~ 122 °F)
Humidity: 20% ~ 80% |
| Viewing System Requirements |
OS: Microsoft Windows 2000/XP/Vista/7
Browser: Mozilla Firefox, Internet Explorer 6.x or above
Cell phone: 3GPP player
Real Player: 10.5 or above
Quick Time: 6.5 or above |
| Installation, Management, and Maintenance |
Installation Wizard 2
32-CH central management software
Supports firmware upgrade |
| Applications |
SDK available for application development and system integration |
| Warranty |
24 months |
